SRP0615-1R0K

Fixed Inductors Overview

The SRP0615-1R0K is a shielded surface-mount power inductor from the Bourns SRP series, designed for high-current applications. It features a compact form factor measuring 7.1mm x 6.7mm x 1.5mm. The component has an inductance of 1 µH with a tolerance of ±10%. It supports a saturation current of 13 A and a DC current rating of 9.8 A. The maximum DC resistance is specified at 13.5 mΩ.

Fixed Inductors Feature Summary

• Shielded construction minimizes electromagnetic interference emissions
• High saturation current capability suitable for demanding power delivery
• Compact surface-mount design optimizes board space utilization

Fixed Inductors Applications

• Point-of-load (POL) voltage regulation modules
• DC-to-DC converter output filtering
• High-density power supply input stages

Fixed Inductors Procurement Notes

Verify the specific suffix 'K' against the manufacturer's official datasheet to confirm the exact inductance value and tolerance class. Ensure the package dimensions match the required PCB footprint constraints. Cross-reference the thermal performance specifications with the intended operating environment to guarantee reliability under load conditions.

Fixed Inductors Selection Notes

Select this component when a balance between high current handling and small physical size is required. The shielded design is critical for applications sensitive to magnetic coupling. Evaluate the DC resistance against allowable voltage drop requirements in the power path. Confirm that the saturation current exceeds the peak transient loads expected in the circuit operation.

Fixed Inductors Part Context

This part belongs to the SRP0615 series of shielded power inductors by Bourns. The series is engineered to meet requirements for high current and low emissions within a small form factor. It complements other Bourns magnetic products used in power management and signal conditioning circuits across industrial and consumer electronics.

Fixed Inductors Replacement Considerations

Consult the official Bourns SRP series documentation for direct cross-references. Verify that any substitute maintains the same 7.1x6.7x1.5mm footprint and shielding characteristics to ensure mechanical and electromagnetic compatibility.
