SRP7030CA-6R8M

$1.39

Description：FIXED IND 6.8UH 6.8A 0.0425OHM
Series：SRP7030CA
Mfr：Bourns Inc.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:50d7a28ef3d3 Category: Fixed Inductors Brand: Bourns Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SRP7030CA-6R8M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Bourns Inc.. Its product description is FIXED IND 6.8UH 6.8A 0.0425OHM. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for SRP7030CA-6R8M

Description：FIXED IND 6.8UH 6.8A 0.0425OHM
Series：SRP7030CA
Mfr：Bourns Inc.
Package：Tape & Reel (TR),Cut Tape (CT)
Type：-
Material - Core：Carbonyl Powder
Inductance：6.8 µH
Tolerance：±20%
Current Rating (Amps)：6.8 A
Current - Saturation (Isat)：12A
Shielding：Shielded
DC Resistance (DCR)：42.5mOhm Max
Q @ Freq：-
Frequency - Self Resonant：14MHz
Ratings：AEC-Q200
Operating Temperature：-55°C ~ 155°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.307" L x 0.299" W (7.80mm x 7.60mm)
Height - Seated (Max)：0.122" (3.10mm)
Features：Flat Wire, High Saturation

Fixed Inductors datasheet and documents for SRP7030CA-6R8M

SRP7030CA-6R8M

Fixed Inductors Overview

The SRP7030CA-6R8M is a shielded surface-mount power inductor from the Bourns SRP7030CA series. It features a ferrite core and flat wire construction, offering high saturation characteristics. The component has an inductance of 6.8 µH with a ±20% tolerance. It supports a maximum DC current of 6.8 A and a saturation current of 14 A. The DC resistance is 42.5 mΩ. Dimensions are 7.8 mm x 7.6 mm x 3.10 mm. Operating temperature range is -55°C to +155°C. It meets AEC-Q200 standards.

Fixed Inductors Feature Summary

Flat wire design for high saturation performance
AEC-Q200 qualified for automotive reliability
Shielded construction to minimize EMI

Fixed Inductors Applications

Automotive electronics systems
High-current power supply circuits
On-board charger applications

Fixed Inductors Procurement Notes

Verify the specific suffix against official Bourns documentation to confirm exact electrical tolerances and packaging options. Confirm RoHS compliance status as per the latest datasheet revision. Ensure the ordering part number matches the required inductance value and current ratings for the target circuit design before finalizing procurement.

Fixed Inductors Selection Notes

Select this component for applications requiring high saturation current within a compact SMD footprint. The flat wire technology provides superior performance compared to traditional round wire designs. Consider the thermal management requirements given the operating temperature range and power dissipation at rated currents when designing the PCB layout.

Fixed Inductors Part Context

This part belongs to the SRP7030CA series of shielded power inductors designed by Bourns. The series is characterized by its robust construction suitable for demanding environments. The CA variant specifically targets automotive and industrial applications requiring high reliability and strict quality standards defined by AEC-Q200 certification.
