SRR6038-150Y

$0.62

Description：FIXED IND 15UH 1.6A 57 MOHM SMD
Series：SRR6038
Mfr：Bourns Inc.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:159bd4aadd3c Category: Fixed Inductors Brand: Bourns Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SRR6038-150Y is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Bourns Inc.. Its product description is FIXED IND 15UH 1.6A 57 MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for SRR6038-150Y

Description：FIXED IND 15UH 1.6A 57 MOHM SMD
Series：SRR6038
Mfr：Bourns Inc.
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Drum Core, Wirewound
Material - Core：Ferrite
Inductance：15 µH
Tolerance：±30%
Current Rating (Amps)：1.6 A
Current - Saturation (Isat)：1.9A
Shielding：Shielded
DC Resistance (DCR)：57mOhm Max
Q @ Freq：8.6 @ 2.52MHz
Frequency - Self Resonant：18MHz
Ratings：-
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.268" L x 0.268" W (6.80mm x 6.80mm)
Height - Seated (Max)：0.157" (4.00mm)
Features：-

Fixed Inductors datasheet and documents for SRR6038-150Y

SRR6038-150Y

Fixed Inductors Overview

The Bourns SRR6038-150Y is a shielded surface-mount power inductor from the SRR6038 series, featuring a wirewound construction on a ferrite core. It provides an inductance of 15 µH with a tolerance of ±30%. The component supports a maximum DC current of 1.6 A and has a maximum DC resistance of 57 mΩ. It operates within a temperature range of -40°C to 125°C and exhibits a minimum quality factor of 8.8. The device is housed in a compact 6.8mm x 6.8mm x 3.8mm molded package with surface mount terminations.

Fixed Inductors Feature Summary

Shielded wirewound design minimizes electromagnetic interference for stable circuit operation
Molded construction protects internal components while maintaining a low profile
Ferrite core material enables efficient energy storage and filtering capabilities

Fixed Inductors Applications

Power supply circuits for filtering and energy storage
DC-DC converter modules
General power electronics applications

Fixed Inductors Procurement Notes

Verify the specific part number against official manufacturer documentation to confirm electrical parameters and physical dimensions. Ensure compatibility with automated pick-and-place equipment by checking reel specifications and tape-and-reel packaging details. Cross-reference thermal ratings with system requirements to guarantee reliable performance under operating conditions.

Fixed Inductors Selection Notes

Select this component when a shielded inductor with moderate current handling is required. The 15 µH value suits specific filtering needs in power conversion stages. Consider the 1.6 A saturation current limit and 57 mΩ resistance for efficiency calculations. The surface-mount form factor allows for high-density PCB layouts compared to through-hole alternatives.

Fixed Inductors Part Context

This component belongs to the SRR6038 series of shielded SMD power inductors manufactured by Bourns. The series offers various inductance values tailored for different power management applications. The SRR6038 designation indicates the physical footprint and height characteristics common to this family of components.
