SRU1028A-560Y

Fixed Inductors Overview

The SRU1028A-560Y is a shielded surface-mount power inductor from the Bourns SRU1028A series. It features a nominal inductance of 56 µH with a tolerance of ±30%. The component has a maximum DC resistance of 0.27 ohms and a saturation current rating of 1 A. The physical length is 10 mm.

Fixed Inductors Feature Summary

• Shielded magnetic structure to minimize electromagnetic interference
• Designed for surface-mount technology integration
• Compliant with automotive reliability standards

Fixed Inductors Applications

• Automotive electronic systems
• Power factor correction circuits
• DC-DC converter modules

Fixed Inductors Procurement Notes

Verify the specific part number against official manufacturer documentation to ensure accuracy. Confirm that the component meets all required electrical specifications for the intended design. Check for any recent product change notices or manufacturing site updates that may affect supply chain logistics or material composition.

Fixed Inductors Selection Notes

Select this component based on its 56 µH inductance and 1 A saturation current requirements. Ensure the PCB layout accommodates the 10 mm length constraint. Verify that the thermal performance and DC resistance values align with the system's efficiency targets and voltage drop limitations.

Fixed Inductors Part Context

This inductor belongs to the SRU1028A series, which provides shielded power inductors for compact applications. The series supports various inductance values while maintaining consistent physical dimensions. It is engineered for high-reliability environments requiring robust magnetic shielding and stable performance under load conditions.

Fixed Inductors Replacement Considerations

Consult official substitution guides for compatible alternatives within the same series. Verify that any substitute part matches the critical parameters of inductance, current rating, and physical footprint before implementation.
