SRU1048A-560Y

Fixed Inductors Overview

The SRU1048A-560Y is a shielded power inductor from Bourns Inc., featuring a drum core wirewound construction with an iron ferrite magnetic material. It offers a nominal inductance of 56 µH with a tolerance of ±30%. The component supports a maximum current rating of 1.6 A and reaches saturation at 1.4 A, while maintaining a maximum DC resistance of 145 mΩ. Designed for surface mount installation, it operates within a temperature range of -40°C to 125°C and holds AEC-Q200 qualification.

Fixed Inductors Feature Summary

• Shielded drum core wirewound design utilizing iron ferrite material
• AEC-Q200 qualified for automotive reliability standards
• High thermal stability supporting operation up to 125°C

Fixed Inductors Applications

• Automotive electronics systems requiring AEC-Q200 compliance
• Space-constrained portable electronic devices
• Industrial control equipment power circuits

Fixed Inductors Procurement Notes

Verify the specific ordering suffix matches the required packaging format, such as tape and reel or cut tape, as indicated by distributor part numbers. Confirm that the requested quantity aligns with standard manufacturing lead times and availability status. Ensure the component meets RoHS3 specifications and REACH requirements for your target market regulations before finalizing procurement orders.

Fixed Inductors Selection Notes

Select this inductor when a shielded solution is necessary to minimize electromagnetic interference in dense circuit layouts. The 56 µH value and 1.6 A current rating suit applications requiring moderate energy storage with compact footprint constraints. Consider the 145 mΩ DCR for efficiency calculations and ensure the operating environment remains within the specified -40°C to 125°C temperature range for optimal performance.

Fixed Inductors Part Context

This component belongs to the SRU1048A series of shielded power inductors designed for space-constrained applications. The series emphasizes high current handling capabilities and low profile dimensions suitable for modern surface mount technologies. The SRU1048A-560Y specifically provides a balanced combination of inductance and current capacity for general power management tasks.

Fixed Inductors Replacement Considerations

Consult official Bourns documentation for direct cross-reference data. Verify that any substitute component maintains equivalent shielding characteristics, AEC-Q200 qualification if required, and compatible physical dimensions for PCB integration.
