SRU6025A-6R8Y

Fixed Inductors Overview

The Bourns SRU6025A-6R8Y is a shielded surface-mount power inductor from the SRU6025 series, featuring a ferrite core and wirewound construction. It provides an inductance of 6.8 µH with a tolerance of ±30%. The component supports a maximum DC current of 2.4 A and has a maximum DC resistance of 42 mΩ. Key electrical parameters include a saturation current of 1.3 A, a minimum Q factor of 8 at 7.96 MHz, and a self-resonant frequency of 36 MHz. It operates within a temperature range of -40°C to +125°C and measures 6.5 mm x 6.2 mm x 2.5 mm.

Fixed Inductors Feature Summary

• Shielded design minimizes electromagnetic interference for stable circuit performance.
• Ferrite core material ensures reliable operation across wide temperature ranges.
• Wirewound structure supports high-current applications with low DC resistance.

Fixed Inductors Applications

• LED driver circuits
• Current control systems
• Power delivery modules

Fixed Inductors Procurement Notes

Verify the specific part number suffix against official Bourns documentation to confirm exact specifications. Ensure that ordering requirements align with manufacturer datasheets rather than distributor summaries. Confirm RoHS compliance status directly through certified product sheets. Validate package options such as cut tape or reel availability via authorized channels. Cross-reference technical parameters with the latest public data to avoid discrepancies.

Fixed Inductors Selection Notes

Choose this component when a shielded SMD inductor with a 6.8 µH value is required for power applications. Consider the 2.4 A maximum DC current rating and 1.3 A saturation limit for load conditions. The 6025 footprint suits space-constrained designs. Verify thermal performance within the -40°C to +125°C operating range. Ensure compatibility with existing PCB layout dimensions and impedance requirements.

Fixed Inductors Part Context

This component belongs to the Bourns SRU6025 series of shielded power inductors. The series offers various inductance values in a compact 6025 surface-mount package. These inductors are designed for general power electronics applications requiring reliable magnetic shielding and consistent performance under varying load conditions.

Fixed Inductors Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Consult official Bourns documentation for potential cross-references or series alternatives.
