SS10X7X4.5W

Overview

The SS10X7X4.5W is a solid free-hanging ferrite core manufactured by Toshiba Semiconductor and Storage, designed for electromagnetic interference suppression in cable assemblies. The component features a cylindrical geometry with an inner diameter of 5.80 mm (0.228 inches) and an outer diameter of 11.50 mm (0.453 inches). Its physical length measures 6.60 mm (0.260 inches). Classified under the Spike Killer series, this round-type ferrite bead provides a robust solution for noise reduction without requiring mechanical mounting hardware.

Feature Summary

• Solid construction allows for free-hanging installation on cables
• Round design facilitates easy sliding onto wire harnesses
• Integrated ferrite material attenuates high-frequency electromagnetic noise

Applications

• Cable assembly noise suppression
• Electromagnetic interference filtering for wire harnesses
• High-frequency signal integrity enhancement

Procurement Notes

Verify part status carefully as distribution channels may list discontinued items. Confirm exact dimensional tolerances against official datasheets before integration. Ensure compatibility with cable diameters within the specified inner diameter range to maintain effective magnetic coupling and noise attenuation performance.

Selection Notes

Select this component when a non-mountable, slide-on ferrite solution is required for cable management. The solid design eliminates the need for clips or adhesives, simplifying assembly processes. Consider the specific frequency range of interference to ensure the ferrite material properties align with the application's noise spectrum requirements.

Part Context

This component belongs to the AB/LB/SS Series family of ferrite beads and chips from Toshiba. It is categorized under passive components used for EMI suppression. The product serves as a standalone filter element rather than a surface-mount device, offering flexibility in cable-based electronic systems where space constraints allow for external ferrite cores.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify cross-compatibility based on identical inner diameter, outer diameter, and length specifications if sourcing alternatives.
