SS11H-10062-CH

Overview

The KEMET SS11H-10062-CH is a common mode choke from the SS11V/H-CH series, designed for AC line filtering. It features an inductance of 6.2 mH and supports a continuous current of 1 A at 250 VAC. The component utilizes a screw terminal connection type with two pins. Its physical dimensions include a height of 45 mm and a length of 11.1 mm. The unit complies with RoHS standards and is intended for electromagnetic interference suppression in electronic circuits.

Feature Summary

• Provides common mode noise suppression for AC power lines
• Utilizes screw terminals for secure electrical connections
• Designed for integration into AC line filter assemblies

Applications

• Electromagnetic interference (EMI) suppression in consumer electronics
• AC power line filtering for household appliances
• Noise reduction in industrial control systems using AC power

Procurement Notes

Verify the specific suffix CH against the manufacturer's latest documentation to confirm compliance status and pin configuration. Confirm that the 6.2 mH inductance value matches the circuit requirements for the target frequency range. Ensure the 1 A current rating accommodates peak loads without saturation. Check for availability as the part may be marked as not recommended for new designs.

Selection Notes

Select this component when designing AC line filters requiring common mode chokes with screw terminal mounting. The 6.2 mH inductance is suitable for standard EMI suppression tasks. Verify that the 250 VAC voltage rating exceeds the maximum operating voltage of the application. Consider the physical footprint of 45 mm height during PCB or chassis layout planning.

Part Context

This component belongs to the KEMET SS11V/H-CH series of common mode coils. These filters are engineered to suppress electromagnetic interference noise in AC powered devices. The series provides various inductance values to suit different filtering requirements while maintaining a compact form factor suitable for integration into standard electronic enclosures.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Consult KEMET technical support for direct replacements or equivalent components within the SS11V/H-CH series.
