SS24MH is listed in the Single Diodes range at ChipApex. The manufacturer field lists Taiwan Semiconductor Corporation. Its product description is DIODE SCHOTTKY 40V 2A MICRO SMA. Review the specifications below when checking this part for your BOM.
Single Diodes specifications for SS24MH
- Description：DIODE SCHOTTKY 40V 2A MICRO SMA
- Series：-
- Mfr：Taiwan Semiconductor Corporation
- Package：Tape & Reel (TR),Cut Tape (CT)
- Technology：Schottky
- Voltage - DC Reverse (Vr) (Max)：40 V
- Current - Average Rectified (Io)：2A
- Voltage - Forward (Vf) (Max) @ If：600 mV @ 2 A
- Speed：Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr)：-
- Current - Reverse Leakage @ Vr：150 µA @ 40 V
- Capacitance @ Vr, F：35pF @ 4V, 1MHz
- Mounting Type：Surface Mount
- Package / Case：2-SMD, Flat Leads
- Supplier Device Package：Micro SMA
- Operating Temperature - Junction：-55°C ~ 150°C
- Grade：-
- Qualification：-
Single Diodes datasheet and documents for SS24MH
Single Diodes Overview
The SS24MH is a surface-mount Schottky rectifier manufactured by Taiwan Semiconductor Corporation. It features a 40V maximum repetitive peak reverse voltage and a 2A average forward rectified current rating. The device utilizes a Micro SMA (SMB) package, specifically the 2-SMD, flat lead configuration. This component is designed for high-efficiency power conversion applications requiring low forward voltage drop and fast switching characteristics.
Single Diodes Feature Summary
- Schottky barrier technology for enhanced efficiency
- Surface mount construction for automated assembly
- Low forward voltage drop characteristic
- Fast switching capability
Single Diodes Applications
- DC-DC converters
- Power supply circuits
- Free-wheeling diodes in inductive loads
Single Diodes Procurement Notes
Verify the manufacturer part number SS24MH against official Taiwan Semiconductor documentation to confirm specifications. Ensure the package type matches the required Micro SMA footprint. Check for any specific ordering suffixes that may indicate tape-and-reel packaging or environmental compliance variations. Confirm authenticity through authorized distribution channels.
Single Diodes Selection Notes
Select this component when a 40V reverse voltage rating and 2A current capacity are sufficient for the circuit design. The Micro SMA package offers a compact solution for space-constrained PCB layouts. Consider the thermal performance of the surface mount package relative to the expected operating temperature and current load.
Single Diodes Part Context
This component belongs to the Schottky Diodes & Rectifiers category from Taiwan Semiconductor. It is distinct from general-purpose silicon rectifiers due to its faster switching speed and lower forward voltage drop. The Micro SMA package provides a balance between current handling capability and board space efficiency compared to smaller SOD packages.
Single Diodes Replacement Considerations
Consult official substitution guides for equivalent Schottky rectifiers with matching 40V and 2A ratings in compatible surface mount packages. Verify pinout compatibility and thermal characteristics before replacing.
