SS35V-35047

Overview

The KEMET SS35V-35047 is a surface-mount common mode choke designed for filtering electromagnetic interference in high-current applications. It features a rated AC voltage of 250V, a current rating of 3.5A, and an inductance of 4.7mH. The component utilizes a compact SMD package suitable for automated assembly processes.

Feature Summary

• Provides effective common mode noise suppression for differential signal lines
• Supports high continuous current handling up to 3.5A without saturation
• Engineered for direct surface-mount integration into PCB layouts

Applications

• Power supply input filtering
• Data line protection in industrial equipment
• EMI suppression for automotive electronics

Procurement Notes

Verify the specific manufacturer datasheet for detailed impedance curves and thermal derating information. Confirm that the operating environment does not exceed the specified voltage and current ratings to ensure long-term reliability and compliance with safety standards.

Selection Notes

Select this component when designing circuits requiring robust common mode noise attenuation at 250VAC levels. Ensure the PCB footprint matches the physical dimensions of the SS35V series to facilitate proper soldering and mechanical stability during operation.

Part Context

This part belongs to KEMET's SS Coils family, specifically the SS35V/H type series. These components are engineered as shielded inductors to minimize magnetic field leakage while maintaining high performance in space-constrained electronic assemblies.

Replacement Considerations

Consult official KEMET documentation for qualified alternative part numbers within the SS35V series or other compatible common mode chokes that match the 4.7mH inductance and 3.5A current specifications.
