SSA-106-W-G-RA

SSA-106-W-G-RA is listed in the Headers, Receptacles, Female Sockets range at ChipApex. The manufacturer field lists Samtec Inc.. Its product description is CONN RCPT 6POS 0.1 GOLD PCB R/A. Review the specifications below when checking this part for your BOM.

Headers, Receptacles, Female Sockets specifications for SSA-106-W-G-RA

• Description：CONN RCPT 6POS 0.1 GOLD PCB R/A
• Series：SSA
• Mfr：Samtec Inc.
• Package：Bulk,Bulk
• Connector Type：Receptacle, Breakaway
• Contact Type：Female Socket
• Style：Board to Board
• Number of Positions：6
• Number of Positions Loaded：All
• Pitch - Mating：0.100" (2.54mm)
• Number of Rows：1
• Row Spacing - Mating：-
• Mounting Type：Through Hole, Right Angle
• Termination：Wire Wrap
• Fastening Type：Push-Pull
• Contact Finish - Mating：Gold
• Contact Finish Thickness - Mating：10.0µin (0.25µm)
• Insulation Color：Black
• Insulation Height：0.100" (2.54mm)
• Contact Length - Post：0.575" (14.61mm)
• Operating Temperature：-55°C ~ 125°C
• Material Flammability Rating：UL94 V-0
• Contact Finish - Post：-
• Mated Stacking Heights：-
• Ingress Protection：-
• Features：-
• Current Rating (Amps)：-
• Voltage Rating：1000V

Headers, Receptacles, Female Sockets datasheet and documents for SSA-106-W-G-RA
