Product Detailed Parameters
- Description：CMC 1.3MH 3A 2LN TH
- Series：SSR
- Mfr：KEMET
- Package：Bulk
- Filter Type：-
- Number of Lines：2
- Current Rating (Max)：3A
- DC Resistance (DCR) (Max)：60mOhm
- Voltage Rating - DC：-
- Voltage Rating - AC：250V
- Operating Temperature：-25°C ~ 120°C
- Ratings：-
- Approval Agency：-
- Features：-
- Mounting Type：Through Hole
- Size / Dimension：0.866" L x 0.630" W (22.00mm x 16.00mm)
- Height (Max)：0.531" (13.50mm)
- Package / Case：Vertical, 4 PC Pin
- Inductance @ Frequency：1.3 mH @ 10 kHz
- Impedance @ Frequency：-
- Qualification：-
- Grade：-
Download product information
Overview
The KEMET SSR10HS-30013 is a high impedance common mode filter choke designed for AC line filtering applications. It features a ferrite core and through-hole mounting style with wire leads. The component provides an inductance of 1.3 mH at a test frequency of 10 kHz, supporting a maximum DC current of 3 A. It has a maximum DC resistance of 60 mOhms and operates within a temperature range of -25 C to +120 C. Rated for 250 VAC, it measures 18 mm in width, 13.5 mm in height, and 3.5 mm in length.
Feature Summary
- High impedance common mode filtering capability
- Ferrite core construction for effective noise suppression
- Through-hole mounting with wire leads for PCB integration
Applications
- Power supply input filtering
- AC line noise reduction
- Electromagnetic interference suppression in electronic equipment
Procurement Notes
Verify the specific part number SSR10HS-30013 against official KEMET documentation to confirm electrical parameters such as inductance and current rating. Ensure compatibility with your circuit's voltage and thermal requirements. Check for RoHS compliance status if required by your manufacturing standards. Confirm package dimensions and lead specifications match your PCB layout constraints before finalizing procurement decisions.
Selection Notes
Select this component when high impedance common mode filtering is required for AC lines. Consider its 3 A current rating and 1.3 mH inductance for appropriate noise attenuation. Evaluate the through-hole mounting style and physical dimensions against available board space. Verify operating temperature range suitability for the intended environment.
Part Context
This component belongs to the KEMET SSR10HS series of common mode chokes. These filters are engineered for power line applications requiring effective electromagnetic interference suppression. The series utilizes ferrite cores to achieve high impedance characteristics across relevant frequency ranges.
Replacement Considerations
Consult official KEMET documentation or authorized distributors for verified substitute part numbers. Cross-referencing requires matching inductance, current rating, and physical dimensions. Do not assume interchangeability without confirming technical specifications from reliable sources.
