SSR21NV-M061200

$1.28

Description：CMC 120MH 600MA 2LN TH
Series：SSR
Mfr：KEMET
Package：Bulk

SKU:12638ddcc080 Category: Common Mode Chokes Brand: KEMET

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 120MH 600MA 2LN TH
Series：SSR
Mfr：KEMET
Package：Bulk
Filter Type：-
Number of Lines：2
Current Rating (Max)：600mA
DC Resistance (DCR) (Max)：1.5Ohm
Voltage Rating - DC：-
Voltage Rating - AC：250V
Operating Temperature：-25°C ~ 120°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：0.866" L x 0.630" W (22.00mm x 16.00mm)
Height (Max)：1.063" (27.00mm)
Package / Case：Vertical, 4 PC Pin
Inductance @ Frequency：120 mH @ 10 kHz
Impedance @ Frequency：-
Qualification：-
Grade：-

Download product information

SSR21NV-M061200

Overview

The KEMET SSR21NV-M061200 is a through-hole common mode filter choke designed for AC line filtering applications. It features an inductance of 120 mH and supports a maximum DC current of 600 mA with a low DC resistance of 1.5 milliohms. Rated for 250 VAC, the component operates within a temperature range of -25°C to +120°C. The physical dimensions are 3.5 mm in length, 16 mm in width, and 27 mm in height, with a diameter of 22 mm. It utilizes a single-channel configuration and is tested at 10 kHz.

Feature Summary

Provides effective common mode noise suppression for AC line circuits
Supports high inductance values for robust EMI filtering performance
Designed for reliable operation in elevated temperature environments up to 120°C

Applications

AC power line input filtering
Electromagnetic interference suppression in electronic equipment
Common mode noise reduction in industrial control systems

Procurement Notes

Verify the complete part number including suffixes to ensure correct inductance and current ratings. Confirm package type matches PCB layout requirements. Check RoHS compliance status if required by specific regulations. Validate operating temperature range against application conditions. Ensure supplier documentation matches the manufacturer datasheet specifications.

Selection Notes

Select this component when high inductance is required for common mode noise attenuation in AC lines. Consider the 600 mA current rating and 1.5 milliohm DC resistance for efficiency. Evaluate the 27 mm height for mechanical clearance constraints. Verify compatibility with through-hole assembly processes. Assess thermal management needs given the 120°C maximum operating temperature limit.

Part Context

This component belongs to the SSR21NV-M series of common mode chokes from KEMET. The series offers various inductance options tailored for AC line filtering. These components are engineered for PCB mounting and provide standardized dimensions for consistent integration. The series focuses on delivering reliable EMI suppression for power supply inputs and signal lines in demanding environments.
