STDCIX1-52M

Overview

The STDCIX1-52M is a surface-mount crystal resonator manufactured by NDK. It operates at a fundamental frequency of 52 MHz with a load capacitance of 8 pF and an equivalent series resistance of 60 Ohms. The component provides a frequency stability of ±10 ppm and functions within a temperature range of -40°C to +85°C. It utilizes a compact 4-SMD, no-lead package measuring 1.2 mm in length and 1.0 mm in width, with a maximum height of 0.4 mm.

Feature Summary

• Compact miniature footprint suitable for space-constrained designs
• High frequency stability for precise timing applications
• Wide operating temperature range for industrial environments

Applications

• Mobile communication devices
• Automotive electronics systems
• IoT sensor modules

Procurement Notes

Verify the specific ordering suffix against official documentation to ensure correct packaging and tolerance specifications. Confirm RoHS compliance status and moisture sensitivity level requirements prior to procurement. Cross-reference manufacturer part numbers with distributor codes to prevent sourcing errors during acquisition.

Selection Notes

Select this component based on its 52 MHz fundamental frequency requirement and strict ±10 ppm stability needs. Ensure the circuit design accommodates the 8 pF load capacitance and 60 Ohm ESR characteristics. Verify that the 1.2x1.0 mm package dimensions fit within the available PCB area and thermal constraints.

Part Context

This device belongs to NDK's line of miniature crystal resonators, leveraging the company's expertise in artificial quartz cultivation. NDK produces these components at facilities in Japan, China, Malaysia, and the US, ensuring consistent quality for global supply chains serving consumer and automotive markets.

Replacement Considerations

STDCIX1-32M
