STMM-105-02-T-D

Headers, Male Pins Overview

The STMM-105-02-T-D is a 2.00 mm pitch shrouded terminal strip manufactured by Samtec, designed for cable-to-board connections. This specific configuration features 10 positions arranged in a dual-row (2x5) layout with a total of 10 contacts. It utilizes through-hole termination for secure PCB mounting and employs square post contacts measuring 0.020 inches (0.51 mm). The housing is constructed from black Liquid Crystal Polymer (LCP) rated UL 94 V-0, ensuring flame resistance. The component operates within a temperature range of -55°C to +105°C and features tin-plated phosphor bronze contacts.

Headers, Male Pins Feature Summary

• Shrouded design provides polarization notch for precise alignment during mating
• Square post contact system ensures reliable retention and low insertion force
• Through-hole termination offers robust mechanical stability on printed circuit boards

Headers, Male Pins Applications

• Cable-to-board interconnects requiring polarized connection
• General purpose electronic assemblies needing reliable signal routing
• Industrial equipment utilizing rugged retention features

Headers, Male Pins Procurement Notes

Verify the exact suffix against the official Samtec catalog to confirm orientation and termination style. Ensure the selected variant matches the required board thickness and mating connector specifications. Confirm RoHS compliance status for the specific production batch before final integration into regulated environments.

Headers, Male Pins Selection Notes

Select this component when a 2.00 mm pitch is required for high-density applications. The dual-row shrouded format is ideal for preventing misalignment during assembly. Consider the through-hole mounting requirement versus surface mount alternatives if space constraints dictate a different profile or thermal management strategy.

Headers, Male Pins Part Context

This part belongs to the STMM series, which specializes in 2.00 mm pitch shrouded terminal strips. The series supports various configurations including right-angle and surface mount options. The STMM-105-02-T-D represents a standard straight-through-hole variant within this family, commonly used in conjunction with TCSD socket cable assemblies for complete connectivity solutions.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Samtec STMM variants with matching pitch and row count but different termination styles, such as STMM-105-02-T-D-SM for surface mount applications. Cross-brand replacements require careful verification of pin spacing, shroud dimensions, and mating interface compatibility.
