STPS3150UF is listed in the Single Diodes range at ChipApex. The manufacturer field lists STMicroelectronics. Its product description is DIODE SCHOTTKY 150V 3A SMBFLAT. Review the specifications below when checking this part for your BOM.
Single Diodes specifications for STPS3150UF
- Description：DIODE SCHOTTKY 150V 3A SMBFLAT
- Series：-
- Mfr：STMicroelectronics
- Package：Tape & Reel (TR),Cut Tape (CT)
- Technology：Schottky
- Voltage - DC Reverse (Vr) (Max)：150 V
- Current - Average Rectified (Io)：3A
- Voltage - Forward (Vf) (Max) @ If：820 mV @ 3 A
- Speed：Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr)：-
- Current - Reverse Leakage @ Vr：2 µA @ 150 V
- Capacitance @ Vr, F：-
- Mounting Type：Surface Mount
- Package / Case：DO-221AA, SMB Flat Leads
- Supplier Device Package：SMBflat
- Operating Temperature - Junction：175°C (Max)
- Grade：-
- Qualification：-
Single Diodes datasheet and documents for STPS3150UF
Single Diodes Overview
The STPS3150UF is a single Schottky rectifier manufactured by STMicroelectronics, rated for 150 V repetitive peak reverse voltage and 3 A average forward current. It utilizes silicon technology in an SMB (DO-214AA) surface-mount package. Key electrical parameters include a maximum forward voltage of 890 mV at 3 A, a surge forward current capability of 100 A, and a low reverse leakage current of 2 uA. The device operates within a temperature range of -65 C to +175 C junction temperature.
Single Diodes Feature Summary
- Negligible switching losses suitable for high-frequency applications
- Low forward voltage drop for higher efficiency and extended battery life
- Surface mount miniature package with low thermal resistance
- ECOPACK2 component compliant
Single Diodes Applications
- Switch mode power supplies on up to 24 V rails
- High frequency converters
- Consumer electronics such as TV, Set-Top Box, PC, and DVD
Single Diodes Procurement Notes
Verify the specific suffix 'U' against official STMicroelectronics documentation to confirm the exact package type and tape/reel specifications. Ensure the ordering part number matches the required RoHS compliance status and packaging format before procurement.
Single Diodes Selection Notes
Select this component for designs requiring low forward voltage drop to minimize power dissipation in consumer and computer applications. Verify that the 150 V rating and 3 A current capacity align with the circuit's peak reverse voltage and average load requirements.
Single Diodes Part Context
This device belongs to the STPS3150 series of power Schottky rectifiers. The series offers various package options including axial, SMA Flat Notch, and SMB Flat, designed to provide low drop forward voltage for reduced power dissipation in compact electronic systems.
Single Diodes Replacement Considerations
Cross-reference with other STPS3150 variants such as STPS3150U or STPS3150Y to verify package compatibility and electrical parameter alignment. Confirm that substitute devices meet the same 150 V and 3 A ratings.
