STPTIC-82G2C5

Overview

The STPTIC-82G2C5 is an analog tunable capacitor IC from STMicroelectronics, designed for RF applications in GSM, LTE, and W-CDMA bands. It operates within a frequency range of 700 MHz to 2.7 GHz. The device features a capacitance range of 1.53 pF to 10.86 pF, with a typical value of 8.2 pF. It is housed in an 8-WLCSP package measuring 0.9 mm in length and 0.3 mm in height. The component supports surface mount installation and has a maximum operating temperature of 85°C.

Feature Summary

• Provides excellent RF performance suitable for adaptive tuning applications
• Ensures low power consumption for efficient operation
• Delivers high linearity required in RF signal processing

Applications

• GSM frequency band tuning
• LTE network integration
• W-CDMA system adaptation

Procurement Notes

Verify the current lifecycle status before procurement, as this component is scheduled for obsolescence and will be discontinued by the manufacturer. Confirm that the 8-WLCSP package dimensions and pin configuration match your PCB layout requirements. Ensure compatibility with the specified 700 MHz to 2.7 GHz operational range for your specific RF design needs.

Selection Notes

Select this component when designing for GSM, LTE, or W-CDMA systems requiring adaptive RF tuning. Consider its small 8-WLCSP footprint for space-constrained layouts. Evaluate its 1.53 pF to 10.86 pF capacitance range against your circuit's impedance matching requirements. Verify thermal stability up to 85°C for your operating environment.

Part Context

This part belongs to the STPTIC series of integrated tunable capacitors from STMicroelectronics. These components are engineered for RF front-end modules where variable capacitance is needed for impedance matching and filtering. The series emphasizes compactness and performance in wireless communication devices.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Due to the scheduled obsolescence status, alternative sourcing strategies should be evaluated immediately.
