SU9H-R01180

$0.92

Description：CMC 18MH 100MA 2LN TH
Series：SU
Mfr：KEMET
Package：Tray

SKU:b7dd713aac5c Category: Common Mode Chokes Brand: KEMET

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 18MH 100MA 2LN TH
Series：SU
Mfr：KEMET
Package：Tray
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：100mA
DC Resistance (DCR) (Max)：8Ohm
Voltage Rating - DC：-
Voltage Rating - AC：250V
Operating Temperature：-25°C ~ 120°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：0.669" L x 0.610" W (17.00mm x 15.50mm)
Height (Max)：0.492" (12.50mm)
Package / Case：Vertical, 4 PC Pin
Inductance @ Frequency：18 mH @ 1 kHz
Impedance @ Frequency：-
Qualification：-
Grade：-

Download product information

SU9H-R01180

Overview

The KEMET SU9H-R01180 is a surface-mount common mode filter from the SU-9H series. It features an inductance of 18 mH and a maximum DC resistance of 8 ohms. The component supports a DC current rating of 100 mA and operates within a temperature range of -40°C to +120°C.

Feature Summary

Utilizes proprietary ferrite material suitable for frequencies greater than or equal to 150 kHz
Designed for high-performance common mode noise suppression in compact surface-mount configurations

Applications

High-frequency signal line filtering
Data bus protection circuits
EMI suppression in automotive electronics

Procurement Notes

Verify the specific suffix against official KEMET documentation to confirm exact electrical tolerances and packaging specifications. Ensure the selected variant matches the required inductance and current ratings for the target application circuit design.

Selection Notes

Select this component when space-constrained designs require effective common mode noise attenuation above 150 kHz. Evaluate the 100 mA current rating and 8 ohm DC resistance to ensure compatibility with the signal integrity requirements of the protected data lines.

Part Context

This part belongs to the SU-9H series of unencapsulated stacked chip filters manufactured by KEMET. These components are engineered for robust performance in demanding environments, offering reliable noise reduction capabilities compared to standard inductive solutions.

Replacement Considerations

Consult official KEMET substitution guides for verified equivalents. Cross-reference inductance values and physical dimensions to ensure mechanical fit and electrical performance parity in existing layouts.
