SVC75C3D17A2-50.000M

Oscillators Overview

The SVC75C3D17A2-50.000M is a Voltage Controlled Crystal Oscillator (VCXO) manufactured by Suntsu Electronics, Inc. It operates at a nominal frequency of 50 MHz with a CMOS output type. The device supports a supply voltage of 3.3V and features an Enable/Disable function for power management. It is housed in a 6-SMD, No Lead package and is designed to operate within a temperature range of -10°C to +70°C, with a typical current consumption of 25mA.

Oscillators Feature Summary

• Voltage controlled crystal oscillator architecture utilizing a ceramic surface-mount design
• CMOS output interface compatible with standard digital logic circuits
• Integrated enable and disable control functionality for system power optimization

Oscillators Applications

• Clock generation in communication systems requiring frequency tuning
• Data transmission equipment needing stable reference signals
• Electronic devices utilizing VCXO-based phase-locked loops

Oscillators Procurement Notes

Verify the specific operating temperature range and current consumption against the official datasheet before integration. Confirm that the 3.3V supply voltage aligns with the target circuit design. Ensure the 6-SMD package dimensions match the PCB footprint requirements. Cross-reference the part number suffix to confirm the exact frequency tolerance and load capacitance specifications required for the application.

Oscillators Selection Notes

Select this component when a 50 MHz reference signal with voltage-controlled frequency adjustment is required. The CMOS output simplifies interfacing with digital processors. Consider the -10°C to +70°C industrial temperature range for environmental suitability. The enable/disable feature allows for dynamic power management in battery-operated or energy-efficient designs compared to always-on oscillators.

Oscillators Part Context

This model belongs to the SVC75 series of ceramic SMT VCXOs from Suntsu Electronics. These components are designed for applications requiring precise frequency control through a control voltage input. The series typically offers low phase noise and high stability, making them suitable for timing-critical applications where frequency agility is necessary beyond fixed-frequency crystal oscillators.

Oscillators Replacement Considerations

Direct substitutes must match the 50 MHz frequency, 3.3V supply, CMOS output, and 6-SMD package. Verify pinout compatibility and control voltage ranges. Check if alternative manufacturers offer equivalent VCXO performance metrics such as pullability and phase noise specifications.
