SX0B25.000F0810F30

Crystals Overview

The SX0B25.000F0810F30 is a passive surface-mount crystal oscillator manufactured by Shenzhen SCTF Electronics. It operates at a fundamental frequency of 25 MHz with a room temperature frequency tolerance of ±10 ppm and a load stability of ±30 ppm. The component features an 8 pF load capacitance and a maximum series resistance of 200 Ohms. It is housed in a compact SMD1612-4P package, designed for lead-free assembly processes compliant with ROHS standards. The device supports a wide operating temperature range from -40°C to +85°C, ensuring reliable performance in various electronic applications requiring precise timing signals.

Crystals Feature Summary

• Compact SMD1612-4P surface-mount package design
• High precision frequency stability within specified tolerances
• Wide operational temperature range capability
• Lead-free construction compliant with environmental standards

Crystals Applications

• General purpose clock signal generation
• Microcontroller timing circuits
• Communication interface synchronization
• Consumer electronics timing references

Crystals Procurement Notes

Verify the specific suffix codes against the manufacturer's official documentation to ensure exact parameter matching. Confirm that the required load capacitance and frequency tolerance align with the target circuit design specifications. Check for any recent updates to the RoHS compliance status or packaging quantities. Ensure that the supplier provides valid traceability documents and original manufacturer certification to guarantee component authenticity and quality assurance during procurement.

Crystals Selection Notes

Select this component when a 25 MHz reference signal is required in space-constrained designs utilizing the SMD1612-4P footprint. Consider the ±10 ppm initial accuracy and ±30 ppm load stability requirements relative to the system's timing budget. Evaluate the 200 Ohm maximum series resistance against the oscillator circuit's drive level constraints. Ensure the -40°C to +85°C operating range covers the intended environmental conditions of the final application without derating issues.

Crystals Part Context

This part belongs to the SCTF SMD crystal oscillator family, characterized by small form factors and high reliability. The SX0B series typically offers standardized pin configurations compatible with automated pick-and-place manufacturing processes. These components are engineered to provide stable frequency references for digital systems, replacing larger through-hole alternatives while maintaining similar electrical performance characteristics across the product line.

Crystals Replacement Considerations

Direct substitutes must match the 25 MHz frequency, 8 pF load capacitance, and SMD1612-4P package dimensions. Verify equivalent frequency stability and series resistance parameters. Cross-reference pinout compatibility if sourcing from alternative manufacturers. No specific public substitute part numbers are confirmed in the provided data.
