SX1B24.000F0910F30

Crystals Overview

The SX1B24.000F0910F30 is a surface-mount crystal oscillator manufactured by Shenzhen SCTF Electronics, designed for precise frequency generation in electronic circuits. It operates at a nominal frequency of 24MHz with a standard load capacitance of 9pF. The component exhibits a typical initial frequency tolerance of ±10ppm and a total frequency stability of ±30ppm across the operating temperature range. Its equivalent series resistance (ESR) is specified at 200Ω, ensuring efficient energy transfer within the oscillation circuit while maintaining signal integrity.

Crystals Feature Summary

• Surface-mount package design suitable for automated assembly processes
• Stable frequency output maintained within specified tolerance limits
• Optimized electrical characteristics for reliable oscillator circuit integration

Crystals Applications

• Microcontroller clock sources
• Communication interface timing
• Digital signal processing systems

Crystals Procurement Notes

Verify the manufacturer datasheet for exact mechanical dimensions and soldering profile recommendations. Confirm that the load capacitance requirements match the host circuit design to ensure accurate frequency performance. Check for any specific storage or handling instructions related to electrostatic discharge sensitivity.

Crystals Selection Notes

Select this component when a 24MHz reference frequency is required with moderate stability needs. Ensure the application environment stays within the specified temperature range to maintain the ±30ppm stability guarantee. Compare ESR values against the oscillator circuit's drive level specifications to prevent overdriving or insufficient startup.

Crystals Part Context

This part belongs to the series of passive crystal resonators produced by Shenzhen SCTF Electronics. These components are widely used in consumer electronics and industrial control systems where compact size and reliable timing are essential. The model number encodes key parameters such as frequency, load capacitance, and tolerance levels.

Crystals Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. When replacing, ensure the new component matches the 24MHz frequency, 9pF load capacitance, and compatible package footprint.
