SX1B27.000F1210F30

Crystals Overview

The SX1B27.000F1210F30 is a surface-mount passive crystal oscillator manufactured by Shenzhen SCTF Electronics. It operates at a fundamental frequency of 27 MHz with a normal temperature frequency tolerance of ±10 ppm and a frequency stability of ±30 ppm. The component features a load capacitance of 10 pF and an equivalent series resistance (ESR) of 60 Ohms. It is housed in a 4-SMD, no-lead package suitable for automated assembly processes.

Crystals Feature Summary

• Surface-mount passive crystal design for compact circuit integration
• Fundamental mode operation at 27 MHz with precise frequency control
• Low equivalent series resistance for efficient signal transmission

Crystals Applications

• Clock generation for microcontrollers and digital logic circuits
• Frequency reference sources in communication modules
• Timing components in consumer electronic devices

Crystals Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to ensure compatibility with required load capacitance and frequency tolerance specifications. Confirm that the 4-SMD package dimensions align with the target PCB footprint and soldering profile requirements before finalizing procurement orders.

Crystals Selection Notes

Select this component when a 27 MHz timing source is required with a 10 pF load capacitance. Ensure the application environment supports the standard operating temperature range and that the 60 Ohm ESR value is compatible with the driving circuit's oscillation conditions. Validate mechanical fit within the designated SMD space constraints.

Crystals Part Context

This part belongs to the SX1B series of surface-mount crystals from Shenzhen SCTF Electronics. The series offers various frequency options and package sizes designed for high-volume manufacturing. The SX1B27.000F1210F30 specifically targets applications requiring stable 27 MHz clock signals in space-constrained designs.

Crystals Replacement Considerations

Cross-reference with other SCTF models such as SX1B27.000F1010F30 if different load capacitance or ESR values are acceptable. Verify pinout and dimensional compatibility before substituting with generic equivalents.
