SX2B24.000F0810F30

Crystals Overview

The SX2B24.000F0810F30 is a surface-mount passive crystal oscillator manufactured by Shenzhen SCTF Electronics. It operates at a nominal frequency of 24.000 MHz and utilizes an SMD package configuration. The component features a load capacitance of 8 pF and maintains a frequency stability of ±30 ppm. Its equivalent series resistance (ESR) is specified at 60 ohms, with a typical tolerance of ±10 ppm.

Crystals Feature Summary

• Surface-mount design for automated assembly
• Stable frequency generation at 24 MHz
• Low equivalent series resistance

Crystals Applications

• Clock signal generation in digital circuits
• Microcontroller timing references
• Communication interface synchronization

Crystals Procurement Notes

Verify the manufacturer part number against official datasheets to ensure authenticity. Confirm that the specific suffix matches the required electrical parameters, including the 24 MHz frequency and 8 pF load capacitance. Check for any variations in package dimensions or ESR values before finalizing procurement orders.

Crystals Selection Notes

Select this component when a precise 24 MHz reference is required for surface-mount applications. Ensure the system design accommodates the 8 pF load capacitance and 60 ohm ESR specifications. Consider the ±30 ppm stability requirement for the intended operating temperature range and environmental conditions.

Crystals Part Context

This model belongs to the SCTF passive crystal family, designed for general-purpose timing applications. It provides a reliable frequency source for electronic systems requiring stable clock signals. The SMD format supports high-volume manufacturing processes.

Crystals Replacement Considerations

Direct substitutes must match the 24 MHz frequency, 8 pF load capacitance, and SMD package type. Verify compatibility with existing circuit designs regarding ESR and stability requirements.
