SX3B13.598F1010F30

Crystals Overview

The SX3B13.598F1010F30 is a surface-mount crystal oscillator manufactured by Shenzhen SCTF Electronics. It operates at a nominal frequency of 13.598 MHz with a normal temperature frequency tolerance of ±10 ppm and a frequency stability of ±30 ppm. The component utilizes a 10 pF load capacitance and features an equivalent series resistance (ESR) of 100 Ohms. It is housed in a compact SMD3225-4P package, designed for integration into electronic circuits requiring precise timing signals.

Crystals Feature Summary

• AT-cut crystal structure providing high precision
• Ultra-small ceramic surface mount construction
• Suitable for high-temperature applications

Crystals Applications

• General-purpose electronic timing circuits
• Embedded systems requiring stable clock sources
• Consumer electronics utilizing surface-mount technology

Crystals Procurement Notes

Verify the specific manufacturer datasheet to confirm RoHS compliance status and exact operating temperature ranges. Ensure that the 13.598 MHz frequency aligns with system requirements, as this value is non-standard compared to common quartz frequencies. Confirm package compatibility with PCB footprint specifications before ordering.

Crystals Selection Notes

Select this component when a 13.598 MHz signal is required with ±10 ppm initial tolerance. The 100 Ohm ESR and 10 pF load capacitance must match the oscillator circuit design. Consider the SMD3225-4P dimensions for space-constrained layouts. Verify thermal performance if the application involves elevated ambient temperatures.

Crystals Part Context

This part belongs to the SCTF crystal oscillator family, characterized by AT-cut resonators and ceramic packaging. These components are engineered for reliability in standard commercial environments. The model designation encodes key electrical parameters including frequency, tolerance, and load capacitance for quick identification.

Crystals Replacement Considerations

No public substitute part numbers are confirmed in available documentation. Cross-reference with other 13.598 MHz crystals only if electrical parameters and package dimensions are identical.
