SX3DF100.000B20F30DNN

Oscillators Overview

The SX3DF100.000B20F30DNN is a 100 MHz active crystal oscillator manufactured by Shenzhen SCTF Electronics. It operates at a supply voltage of 3.3V and utilizes LVDS output mode for signal transmission. The unit features a frequency stability of ±20 ppm and is housed in an SMD3225-6P surface-mount package. Designed for high-speed digital applications, it supports an operating temperature range of -40°C to +85°C. This component provides precise timing signals with low power consumption, suitable for integration into compact electronic systems requiring reliable clock sources.

Oscillators Feature Summary

• LVDS differential output interface for high-speed data integrity
• Compact SMD3225-6P surface-mount packaging
• Wide industrial operating temperature range capability

Oscillators Applications

• High-speed networking equipment
• Communication infrastructure devices
• Digital signal processing systems

Oscillators Procurement Notes

Verify the specific ordering suffix against the manufacturer's official documentation to ensure correct output type and tolerance specifications. Confirm that the SMD3225-6P footprint matches the target PCB design requirements. Check for any recent updates to the datasheet regarding pinout configurations or electrical characteristics before finalizing procurement orders.

Oscillators Selection Notes

Select this model when LVDS signaling is required for noise immunity in dense circuit layouts. Ensure the 3.3V supply rail is stable within specified limits. Consider thermal management if multiple oscillators are placed in close proximity. Verify that the ±20 ppm stability meets the system's jitter and phase noise requirements for the intended application environment.

Oscillators Part Context

This component belongs to the SX3DF series of active crystal oscillators from Shenzhen SCTF Electronics. The series is designed to provide stable clock signals for modern digital electronics. The SX3DF variant specifically targets applications requiring LVDS outputs, offering improved signal quality over single-ended interfaces while maintaining a small form factor suitable for space-constrained designs.

Oscillators Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material.
