SXOA33.330B20F30TNN

Oscillators Overview

The SXOA33.330B20F30TNN is a standard CMOS crystal oscillator manufactured by Shenzhen SCTF Electronics. It operates at a fundamental frequency of 33.33 MHz and utilizes a 3.3V supply voltage. The component features an enable/disable control function for power management. It is housed in an 8-DIP package, specifically configured as a half-size metal can with four pins, suitable for through-hole mounting applications requiring precise timing signals.

Oscillators Feature Summary

• Provides stable 33.33 MHz clock signal generation using CMOS output technology
• Integrates enable and disable functionality for efficient power control
• Constructed within a compact half-size metal can package for durability

Oscillators Applications

• Embedded system clock generation
• Digital logic circuit timing references
• Communication interface synchronization

Oscillators Procurement Notes

Verify the exact operating temperature range and load capacitance requirements against your specific circuit design before ordering. Confirm that the 3.3V logic levels are compatible with your receiving devices. Ensure the half-size DIP footprint matches your PCB layout constraints to avoid assembly issues.

Oscillators Selection Notes

Select this oscillator when a precise 33.33 MHz frequency is required for CMOS-based digital circuits. Consider the enable pin feature if power conservation during idle states is necessary. Evaluate the metal can packaging benefits regarding electromagnetic interference shielding compared to plastic alternatives for sensitive environments.

Oscillators Part Context

This component belongs to the series of standard crystal oscillators produced by Shenzhen SCTF Electronics. These devices are designed to replace discrete crystal and oscillator circuits, offering a compact solution for timing needs. The half-size form factor allows for denser PCB layouts while maintaining the reliability associated with hermetically sealed metal packages.

Oscillators Replacement Considerations

Direct substitutes must match the 33.33 MHz frequency, 3.3V CMOS output, and 8-DIP half-size metal can package. Verify pinout compatibility and electrical specifications such as rise/fall times and duty cycle stability before swapping components.
