SXOA4.032A20F30TNN is listed in the Oscillators range at ChipApex. The manufacturer field lists Shenzhen SCTF Electronics. Its product description is XTAL OSC XO 4.0320MHz CMOS TH. Review the specifications below when checking this part for your BOM.
Oscillators specifications for SXOA4.032A20F30TNN
- Description：XTAL OSC XO 4.0320MHz CMOS TH
- Series：OA
- Mfr：Shenzhen SCTF Electronics
- Package：Tray
- Base Resonator：Crystal
- Type：XO (Standard)
- Frequency：4.032 MHz
- Function：Enable/Disable
- Output：CMOS
- Voltage - Supply：5V
- Frequency Stability：±50ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 85°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：25mA
- Ratings：-
- Mounting Type：Through Hole
- Package / Case：8-DIP, 4 Leads (Half Size, Metal Can)
- Size / Dimension：0.500" L x 0.500" W (12.70mm x 12.70mm)
- Height - Seated (Max)：0.220" (5.60mm)
- Supplier Device Package：-
Oscillators datasheet and documents for SXOA4.032A20F30TNN
Oscillators Overview
The SXOA4.032A20F30TNN is a standard CMOS crystal oscillator manufactured by Shenzhen SCTF Electronics, operating at a nominal frequency of 4.032 MHz. It utilizes an 8-DIP package and requires a 5V supply voltage. The component features a maximum supply current of 25mA and maintains a frequency stability of ±50ppm. It is designed for reliable operation within an extended temperature range spanning from -40°C to +85°C.
Oscillators Feature Summary
- Standard CMOS output signal generation
- Integrated enable/disable control functionality
- Extended industrial temperature range capability
Oscillators Applications
- General-purpose digital timing circuits
- Microcontroller clock sources
- Industrial control system synchronization
Oscillators Procurement Notes
Verify the specific pinout configuration and mechanical dimensions against the official datasheet prior to PCB layout finalization. Ensure that the selected 8-DIP footprint matches the manufacturer's recommended land pattern to guarantee proper soldering reliability and electrical contact integrity during assembly processes.
Oscillators Selection Notes
Select this component when a stable 4.032 MHz reference is required for CMOS logic interfaces. Consider the ±50ppm stability specification against the target application's tolerance requirements. Evaluate the 5V supply constraint and 25mA current draw to confirm compatibility with the available power distribution network in the design.
Oscillators Part Context
This part belongs to the SXOA series of standard oscillators from Shenzhen SCTF Electronics. The series provides fixed-frequency solutions for embedded systems requiring precise timing references without external tuning components. The 8-DIP format offers through-hole mounting options suitable for prototyping or specific industrial enclosure requirements.
Oscillators Replacement Considerations
Consult official cross-reference lists for direct equivalents. Verify that any substitute maintains identical CMOS output levels, 5V supply requirements, and ±50ppm stability specifications to ensure functional compatibility.
