SXOA54.000A20F30TNN

Oscillators Overview

The SXOA54.000A20F30TNN is a standard crystal oscillator manufactured by Shenzhen SCTF Electronics. It operates at a frequency of 54 MHz and utilizes CMOS output logic levels. The device is powered by a single 5V supply voltage and features an enable/disable control function for power management. It is housed in an 8-DIP package with four leads, specifically designed as a half-size metal can configuration suitable for through-hole mounting.

Oscillators Feature Summary

• CMOS output interface providing standard digital signaling compatibility
• Integrated enable and disable control pin for active power state management
• Half-size metal can construction offering electromagnetic interference shielding

Oscillators Applications

• General-purpose clock signal generation in embedded systems
• Timing reference sources for microcontroller-based circuits
• Synchronization modules requiring stable 54 MHz frequencies

Oscillators Procurement Notes

Verify the manufacturer part number SXOA54.000A20F30TNN against official Shenzhen SCTF Electronics documentation to confirm specifications. Ensure the 8-DIP half-size metal can package matches the design requirements. Confirm the 5V supply voltage and CMOS output characteristics align with the target circuit design before procurement.

Oscillators Selection Notes

Select this component when a 54 MHz timing source with CMOS outputs is required. The enable/disable feature supports power-sensitive applications. The half-size metal can package provides shielding benefits while maintaining through-hole compatibility. Verify that the 5V operating voltage fits within the system's power budget and that the DIP footprint accommodates the assembly constraints.

Oscillators Part Context

This oscillator belongs to the standard XO series from Shenzhen SCTF Electronics. It is designed for applications requiring precise frequency stability and reliable operation. The half-size metal can variant offers a compact form factor compared to full-size DIP packages, making it suitable for space-constrained designs while retaining robust shielding properties typical of metal enclosures.

Oscillators Replacement Considerations

Consult official manufacturer substitution lists for verified equivalents. Cross-reference electrical parameters such as frequency tolerance, load capacitance, and drive level when evaluating alternative components. Ensure any substitute maintains the same 8-DIP half-size metal can package and CMOS output logic levels.
