SXOA6.000B20F30TNN

$1.57

Description：XTAL OSC XO 6.0000MHz CMOS TH
Series：OA
Mfr：Shenzhen SCTF Electronics
Package：Tray

SKU:62c9d95a82d9 Category: Oscillators Brand: Shenzhen SCTF Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SXOA6.000B20F30TNN is listed in the Oscillators range at ChipApex. The manufacturer field lists Shenzhen SCTF Electronics. Its product description is XTAL OSC XO 6.0000MHz CMOS TH. Review the specifications below when checking this part for your BOM.

Oscillators specifications for SXOA6.000B20F30TNN

Description：XTAL OSC XO 6.0000MHz CMOS TH
Series：OA
Mfr：Shenzhen SCTF Electronics
Package：Tray
Base Resonator：Crystal
Type：XO (Standard)
Frequency：6 MHz
Function：Enable/Disable
Output：CMOS
Voltage - Supply：3.3V
Frequency Stability：±50ppm
Absolute Pull Range (APR)：-
Operating Temperature：-40°C ~ 85°C
Spread Spectrum Bandwidth：-
Current - Supply (Max)：25mA
Ratings：-
Mounting Type：Through Hole
Package / Case：8-DIP, 4 Leads (Half Size, Metal Can)
Size / Dimension：0.500" L x 0.500" W (12.70mm x 12.70mm)
Height - Seated (Max)：0.220" (5.60mm)
Supplier Device Package：-

Oscillators datasheet and documents for SXOA6.000B20F30TNN

SXOA6.000B20F30TNN

Oscillators Overview

The SXOA6.000B20F30TNN is a standard crystal oscillator manufactured by Shenzhen SCTF Electronics. It operates at a frequency of 6 MHz with a CMOS output signal level. The device functions at a supply voltage of 3.3 V and includes enable/disable control functionality. It utilizes a crystal resonator base element and is designed for through-hole mounting. The component is housed in an 8-DIP package featuring four leads, specifically configured as a half-size metal can.

Oscillators Feature Summary

Provides stable 6 MHz clock signals via CMOS output interface
Integrates enable and disable control capabilities for power management
Utilizes a crystal resonator for precise frequency generation

Oscillators Applications

Embedded system clock sources
Microcontroller timing circuits
Digital logic synchronization

Oscillators Procurement Notes

Verify the manufacturer part number SXOA6.000B20F30TNN against official Shenzhen SCTF Electronics documentation to confirm specifications. Ensure the 8-DIP half-size metal can package matches the design requirements. Confirm that the 3.3V CMOS output and enable/disable features align with the target circuit design before procurement.

Oscillators Selection Notes

Select this component when a 6 MHz clock source with CMOS output is required for through-hole applications. Consider the 3.3V operating voltage and enable/disable control features for system integration. The half-size metal can package offers a compact solution for space-constrained designs requiring reliable crystal oscillator performance.

Oscillators Part Context

This oscillator belongs to the standard XO category from Shenzhen SCTF Electronics. It provides a fixed 6 MHz frequency output suitable for general digital timing applications. The through-hole mounting option allows for easy integration into legacy or specific board layouts requiring robust mechanical connections.
