SXOA66.66666B20F30TNN

Oscillators Overview

The SXOA66.66666B20F30TNN is a CMOS crystal oscillator manufactured by Shenzhen SCTF Electronics. It operates at a nominal frequency of 66.66666 MHz with a supply voltage of 3.3V. The device features a frequency stability of ±50ppm and an operating temperature range of -40°C to 85°C. It utilizes a half-size metal housing package with four leads in a through-hole DIP configuration, designed for enable/disable functionality.

Oscillators Feature Summary

• CMOS output signal generation
• Half-size metal housing construction
• Through-hole mounting capability

Oscillators Applications

• General electronic circuit timing
• Industrial control systems
• Consumer electronics devices

Oscillators Procurement Notes

Verify the manufacturer designation as Shenzhen SCTF Electronics against official component documentation. Confirm the specific package dimensions and lead configuration match the half-size DIP requirement. Ensure the frequency tolerance and temperature range align with system design specifications before procurement.

Oscillators Selection Notes

Select this component when a precise 66.66666 MHz clock source is required within the specified industrial temperature range. Consider the CMOS output compatibility with downstream logic circuits. Evaluate the mechanical constraints of the half-size metal housing for PCB layout integration.

Oscillators Part Context

This part belongs to the family of precision crystal oscillators designed for stable clock generation. It provides a reliable alternative to discrete crystal and resonator combinations by integrating the necessary oscillator circuitry into a single packaged unit.

Oscillators Replacement Considerations

No public confirmed substitute part numbers are available in the provided data.
