SXOA7.3728A20F30TNN

Oscillators Overview

The SXOA7.3728A20F30TNN is a CMOS crystal oscillator manufactured by Shenzhen SCTF Electronics. It operates at a frequency of 7.3728 MHz with a supply voltage of 3.3V. The device features a frequency stability of ±50ppm and draws a maximum supply current of 25mA. Designed for through-hole mounting, it utilizes an 8-DIP package configuration. The component supports an operating temperature range from -40°C to +85°C, ensuring reliable performance across standard industrial environments.

Oscillators Feature Summary

• Provides stable clock signals via CMOS output technology
• Supports through-hole integration within 8-DIP packages
• Operates reliably across extended industrial temperature ranges

Oscillators Applications

• Digital system clock generation
• Microcontroller timing circuits
• Embedded system synchronization

Oscillators Procurement Notes

Verify the manufacturer designation matches Shenzhen SCTF Electronics exactly. Confirm the model suffix aligns with the specified 3.3V CMOS output and 8-DIP through-hole package requirements. Ensure the frequency stability meets the ±50ppm specification for the target application environment.

Oscillators Selection Notes

Select this component when a through-hole 8-DIP form factor is required for board layout constraints. Choose based on the specific 3.3V logic level compatibility and the need for ±50ppm frequency accuracy. Consider the -40°C to +85°C operational range against environmental conditions.

Oscillators Part Context

This oscillator belongs to the SXOA series of electronic components designed for timing applications. It serves as a fundamental frequency reference source for digital circuits requiring precise clock synchronization without external tuning components.

Oscillators Replacement Considerations

Public confirmed substitute part numbers are not available in verified documentation.
