SXOA9.8304A20F30TNN

Oscillators Overview

The SXOA9.8304A20F30TNN is a CMOS crystal oscillator manufactured by Shenzhen SCTF Electronics, operating at a frequency of 9.8304 MHz. It utilizes an 8-DIP package with four leads in a half-size metal can configuration. The component supports a 5V enable/disable control function and is designed for through-hole mounting.

Oscillators Feature Summary

• CMOS output signal generation
• Enable/disable control functionality
• Half-size metal can construction

Oscillators Applications

• General electronic timing circuits
• Digital logic systems requiring stable clock signals
• Embedded device synchronization

Oscillators Procurement Notes

Verify the specific manufacturer designation against authorized distributors to ensure authenticity. Confirm that the 8-DIP half-size metal can package matches the required PCB footprint. Ensure the 5V enable/disable pinout aligns with the target circuit design before finalizing procurement orders.

Oscillators Selection Notes

Select this component when a precise 9.8304 MHz clock source is required for digital applications. The CMOS output level is suitable for standard logic interfaces. Consider the through-hole mounting requirement and the physical dimensions of the half-size metal can during board layout planning.

Oscillators Part Context

This oscillator belongs to the family of standard CMOS crystal oscillators. It provides a fixed frequency output without internal tuning adjustments. The metal can package offers shielding against external electromagnetic interference compared to plastic packages.

Oscillators Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
