SXOB3.2768A20F30TNN

Oscillators Overview

The SXOB3.2768A20F30TNN is a standard CMOS oscillator manufactured by Shenzhen SCTF Electronics, operating at a frequency of 3.2768 MHz. It utilizes an 8-DIP package with four leads, specifically designed as a half-size metal can configuration. The component supports a supply voltage of 5V and features CMOS output levels. It includes integrated enable and disable control functionality to manage power consumption during inactive periods.

Oscillators Feature Summary

• Half-size metal can construction for compact integration
• Integrated enable and disable control capability
• CMOS output signal compatibility

Oscillators Applications

• General-purpose clock generation in electronic circuits
• Timing reference sources for digital systems
• Embedded device synchronization modules

Oscillators Procurement Notes

Verify the specific suffix 'A' against official datasheets to confirm the exact voltage rating and pinout configuration. Ensure the half-size DIP package dimensions align with the target PCB footprint requirements. Confirm that the CMOS output swing meets the input threshold specifications of the receiving logic circuitry before finalizing procurement.

Oscillators Selection Notes

Select this component when a precise 3.2768 MHz timing source is required within space-constrained designs. The half-size metal can package offers a smaller footprint compared to standard oscillators while maintaining robust shielding characteristics. Consider the enable/disable feature if system-level power management is a priority for the application design.

Oscillators Part Context

This model belongs to the SXOB series of standard CMOS oscillators from Shenzhen SCTF Electronics. The series provides various frequency options within a standardized half-size metal can form factor. These components are designed to replace larger traditional crystal units with integrated oscillator solutions, offering improved reliability and reduced board space requirements for modern electronics.

Oscillators Replacement Considerations

The SXOA3.2768A20F30TNN is identified as a related variant within the same product family. Verify compatibility regarding voltage ratings and package orientation when considering substitution.
