SXOB49.152A20F30TNN

Oscillators Overview

The SXOB49.152A20F30TNN is a crystal oscillator (XO) manufactured by Shenzhen SCTF Electronics, operating at a frequency of 49.152 MHz. It utilizes CMOS output logic and features through-hole mounting technology. The device is housed in an 8-DIP package with four pins, specifically designed as a half-size metal can configuration. This component provides standard clock signal generation capabilities for electronic circuits requiring precise timing synchronization.

Oscillators Feature Summary

• CMOS output logic interface
• Through-hole mounting construction
• Half-size metal can packaging

Oscillators Applications

• General-purpose clock signal generation
• Timing synchronization in digital circuits
• Standard oscillator applications

Oscillators Procurement Notes

Verify the specific manufacturer datasheet to confirm electrical parameters such as supply voltage, current consumption, and frequency stability before integration. Ensure the selected variant matches the required pinout and mechanical dimensions for the target PCB layout. Cross-reference the official specification sheet to validate performance characteristics against system requirements.

Oscillators Selection Notes

Select this component when a standard CMOS output oscillator with through-hole mounting is required. Consider the half-size metal can package for space-constrained designs needing robust shielding. Verify that the 49.152 MHz frequency aligns with the system's timing needs and that the CMOS output level is compatible with downstream logic inputs.

Oscillators Part Context

This part belongs to the series of crystal oscillators produced by Shenzhen SCTF Electronics. It represents a standard XO solution designed for reliable clock generation. The product line typically includes various frequencies and packages, with this specific model focusing on the 49.152 MHz range using a compact through-hole metal can form factor.

Oscillators Replacement Considerations

Check for direct substitutes from the same manufacturer or other suppliers offering identical 49.152 MHz CMOS oscillators in 8-DIP half-size metal cans. Ensure compatibility regarding pin configuration, output logic type, and mechanical footprint before substitution.
