SXOB50.000A20F30TNN

Oscillators Overview

The SXOB50.000A20F30TNN is a 50 MHz CMOS crystal oscillator manufactured by Shenzhen SCTF Electronics. It operates at a supply voltage of 5V and features an Enable/Disable control function. The component utilizes a standard half-size metal can package with 8-DIP, 4 leads configuration. This surface-mount or through-hole compatible device provides stable clock signals for digital circuits requiring precise timing synchronization.

Oscillators Feature Summary

• Integrated enable/disable functionality for power management
• CMOS output logic levels for direct interface compatibility
• Half-size metal can construction for electromagnetic shielding

Oscillators Applications

• Digital signal processing systems
• Communication equipment clocking
• Microcontroller system timing

Oscillators Procurement Notes

Verify the manufacturer designation Shenzhen SCTF Electronics against official component markings. Confirm the 50 MHz frequency and 5V operating voltage match system requirements. Ensure the 8-DIP 4-lead half-size metal can package dimensions align with PCB footprint specifications before procurement.

Oscillators Selection Notes

Select this oscillator when a 50 MHz CMOS clock source with hardware enable control is required. The half-size metal can package offers compact integration while providing shielding benefits. Verify that the 5V supply voltage is compatible with the target circuit design and that the enable pin functionality supports system power sequencing needs.

Oscillators Part Context

This component belongs to the series of standard CMOS oscillators designed for general-purpose timing applications. The half-size metal can format distinguishes it from larger DIP packages while maintaining robust performance characteristics suitable for industrial and commercial electronic devices requiring reliable clock generation.

Oscillators Replacement Considerations

Cross-reference with other 50 MHz CMOS oscillators in half-size metal cans. Verify pinout compatibility and electrical parameters such as supply voltage and output logic levels before substitution.
