SXOB66.6666B20F30TNN

Oscillators Overview

The SXOB66.6666B20F30TNN is a CMOS crystal oscillator manufactured by Shenzhen SCTF Electronics, operating at a nominal frequency of 66.6666 MHz. It utilizes a standard 8-DIP package with four leads, specifically designed as a half-size metal can component for through-hole mounting. The device supports a supply voltage of 3.3V and features enable/disable functionality to manage power consumption. It offers a frequency stability of ±50ppm and operates within a temperature range of -40°C to 85°C. The maximum supply current is rated at 60mA, ensuring efficient performance in various electronic applications requiring precise timing signals.

Oscillators Feature Summary

• Provides stable clock signals with ±50ppm frequency stability for reliable system synchronization
• Features an enable/disable control pin to optimize power management during idle states
• Utilizes a compact half-size metal can package suitable for space-constrained designs

Oscillators Applications

• General-purpose digital systems requiring precise timing references
• Communication equipment utilizing standard CMOS clock interfaces
• Industrial control units operating within extended temperature ranges

Oscillators Procurement Notes

Verify the specific ordering suffixes to ensure compatibility with required frequency stability and temperature ratings. Confirm that the 8-DIP half-size package aligns with your PCB footprint requirements. Check for RoHS compliance status if environmental regulations apply to your manufacturing process. Ensure the 3.3V supply voltage matches your system's logic levels before integration.

Oscillators Selection Notes

Select this component when a standard CMOS output is required for clock distribution. Consider the ±50ppm stability limit against your system's jitter tolerance. Evaluate the through-hole mounting option against surface-mount alternatives if mechanical robustness is prioritized. Verify that the 60mA current draw fits within your power budget constraints.

Oscillators Part Context

This oscillator belongs to the series of standard CMOS timing devices produced by Shenzhen SCTF Electronics. It serves as a fundamental timing source for digital circuits, replacing discrete crystal and resonator combinations. The half-size DIP format allows for easier manual handling and prototyping compared to smaller surface-mount packages while maintaining standard electrical characteristics.

Oscillators Replacement Considerations

Direct substitutes must match the 66.6666 MHz frequency, 3.3V operation, and 8-DIP half-size package. Verify that alternative manufacturers offer identical ±50ppm stability and -40°C to 85°C temperature ranges. Ensure the replacement part maintains the same enable/disable functionality and CMOS output voltage levels.
