SXOB66.666B20F30TNN

Oscillators Overview

The SXOB66.666B20F30TNN is a crystal oscillator manufactured by Shenzhen SCTF Electronics, operating at a nominal frequency of 66.666 MHz. It utilizes CMOS output logic and functions as an enable/disable device. The component requires a 3.3V supply voltage and maintains a frequency stability of ±50ppm. This surface-mount oscillator is designed for precise timing applications requiring stable clock signals within electronic circuits.

Oscillators Feature Summary

• Provides stable CMOS output signals for digital circuit synchronization
• Features enable and disable functionality for power management control
• Maintains high frequency stability to ensure accurate timing performance

Oscillators Applications

• Digital signal processing systems requiring precise clock sources
• Communication equipment utilizing standard CMOS interfaces
• Embedded systems needing reliable timing references

Oscillators Procurement Notes

Verify the specific frequency value against official datasheets, as similar part numbers may indicate different decimal precision. Confirm that the CMOS output type matches the target circuit requirements. Ensure the 3.3V supply voltage aligns with the system design specifications before procurement.

Oscillators Selection Notes

Select this component when a 66.666 MHz clock source with CMOS output is required. Consider the ±50ppm stability requirement for timing-sensitive designs. Verify compatibility with the 3.3V operating voltage and ensure the enable/disable feature supports the system's power management strategy.

Oscillators Part Context

This oscillator belongs to the series of surface-mount crystal oscillators produced by Shenzhen SCTF Electronics. These components are engineered to provide reliable clock signals for various electronic applications. The specific model offers a standardized frequency suitable for common digital interface standards.

Oscillators Replacement Considerations

Check for direct substitutes from the same manufacturer with identical pinout and electrical characteristics. Ensure any replacement maintains the 66.666 MHz frequency, CMOS output type, and 3.3V supply requirement. Verify that the stability specification meets or exceeds the original ±50ppm tolerance.
