SXOB8.000B20F30TNN

Oscillators Overview

The SXOB8.000B20F30TNN is a standard CMOS crystal oscillator manufactured by Shenzhen SCTF Electronics, operating at a nominal frequency of 8 MHz. It utilizes an enable/disable control interface and supports a supply voltage range of 1.8V to 3.3V. The component is housed in an 8-DIP package with four leads, specifically designed as a half-size metal can configuration. This oscillator is engineered for stable performance across varying power supply conditions within the specified voltage limits.

Oscillators Feature Summary

• Features an enable/disable control interface for power management
• Operates on standard CMOS output signals
• Housed in a compact half-size metal can package

Oscillators Applications

• Embedded systems requiring precise clock timing
• Communication equipment signal processing
• Consumer electronics with low power constraints

Oscillators Procurement Notes

Verify the specific ordering suffix against the manufacturer's official documentation to ensure compatibility with required voltage levels and load capacitance specifications. Confirm that the half-size DIP package dimensions align with the target PCB footprint requirements before finalizing procurement orders.

Oscillators Selection Notes

Select this component when a standard CMOS oscillator with enable functionality is required. Ensure the design accommodates the 1.8V to 3.3V operating range. Consider the physical size of the half-size metal can package during layout planning to maintain adequate clearance and thermal management.

Oscillators Part Context

This part belongs to the SXOB series of crystal oscillators from Shenzhen SCTF Electronics. The series offers various frequency options and packaging styles. The SXOB8.000B20F30TNN represents a specific configuration optimized for 8 MHz applications with standard CMOS outputs and half-size metal can housing.

Oscillators Replacement Considerations

Cross-reference with other SCTF SXOB series models for alternative frequencies or package types. Verify pinout compatibility and electrical parameters before substituting with components from different manufacturers.
