SXT3248ED48-14.7456M

Crystals Overview

The SXT3248ED48-14.7456M is a surface-mount crystal manufactured by Suntsu Electronics, Inc., operating at a nominal frequency of 14.7456 MHz. It features an 8 pF load capacitance and a series resistance of 100 Ohms. The component exhibits a normal temperature frequency tolerance of ±15 ppm and a frequency stability of ±25 ppm across the specified operating range. Designed for compact electronic applications, it utilizes a 4-SMD, No Lead package configuration to facilitate automated assembly processes.

Crystals Feature Summary

• Surface-mount design with no lead configuration for efficient PCB integration
• Precision timing capability with defined frequency tolerance and stability metrics
• Optimized electrical characteristics including specific load capacitance and series resistance

Crystals Applications

• Digital signal processing circuits requiring precise clock synchronization
• Communication systems utilizing standard baud rates derived from 14.7456 MHz
• Microcontroller-based embedded systems needing stable oscillator sources

Crystals Procurement Notes

Verify that the ordered component matches the exact part number SXT3248ED48-14.7456M to ensure correct frequency and package specifications. Confirm RoHS compliance status if environmental regulations apply to your manufacturing process. Request official datasheets or test reports from authorized distributors to validate authenticity and performance parameters before finalizing procurement decisions.

Crystals Selection Notes

Select this component when a 14.7456 MHz frequency is required for system clocking or data transmission standards. Ensure the application circuit supports an 8 pF load capacitance to maintain accurate frequency output. Consider the 4-SMD no-lead package dimensions for board space constraints and verify that the operating temperature range meets the environmental requirements of the end product.

Crystals Part Context

This model belongs to the SXT324 series of MHz crystals from Suntsu Electronics, Inc. The series typically includes various frequencies within the tuning fork crystal category. The SXT3248ED48 variant specifically denotes the package style and electrical characteristics associated with this family of precision timing components designed for surface-mount technology applications.

Crystals Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with alternative suppliers by matching frequency, load capacitance, package type, and stability specifications. Consult manufacturer cross-reference lists for potential equivalents if supply chain adjustments are necessary.
