SXT53410BD27-25.000M

Crystals Overview

The SXT53410BD27-25.000M is a surface-mount crystal oscillator manufactured by Suntsu Electronics, Inc. It operates at a fundamental frequency of 25.000 MHz with a frequency tolerance of ±30ppm and a load capacitance of 10pF. The component features an equivalent series resistance (ESR) of 70 Ohms and utilizes a 4-SMD, No Lead package configuration. This device is designed for precision timing applications requiring stable frequency generation in compact electronic circuits.

Crystals Feature Summary

• Surface-mount design for automated assembly
• Fundamental mode quartz crystal operation
• RoHS compliant construction

Crystals Applications

• Microcontroller clock sources
• Communication module timing references
• Digital signal processing circuits

Crystals Procurement Notes

Verify the specific suffix BD27 against the official Suntsu Electronics datasheet to confirm pinout and mechanical dimensions. Ensure the operating temperature range meets system requirements. Confirm RoHS compliance status through current manufacturer documentation rather than distributor summaries.

Crystals Selection Notes

Select this component when a 25 MHz fundamental frequency with ±30ppm stability is required. The 10pF load capacitance must match the oscillator circuit design. Consider the 70 Ohm ESR value for drive level sensitivity. The 4-SMD package dictates PCB footprint constraints.

Crystals Part Context

This part belongs to the SXT53410 series of ceramic surface-mount crystals from Suntsu Electronics. The series offers various frequency options within standard packaging. The BD27 suffix indicates specific mechanical and electrical characteristics distinct from other variants like DE16 or CC16.

Crystals Replacement Considerations

Direct substitutes include SXT53410BD16-25.000M if mechanical height differences are acceptable. Verify compatibility with SXT53410DE16-25.000M only after confirming package dimension tolerances. Cross-reference with SXT21418BB38-25.000M requires careful evaluation of package type differences.
