SXTHM212DD074-24.000M

Crystals Overview

The SXTHM212DD074-24.000M is a surface-mount crystal oscillator manufactured by Suntsu Electronics, Inc. It operates at a fundamental frequency of 24.000 MHz with a frequency tolerance of ±20 ppm. The component features a load capacitance of 12 pF and an equivalent series resistance (ESR) of 30 Ohms. It utilizes the HC-49/US package format for standard mounting applications.

Crystals Feature Summary

• Provides precise timing signals at 24 MHz with high stability
• Designed for surface-mount technology integration
• Optimized low impedance characteristics for efficient circuit operation

Crystals Applications

• Precision timing circuits requiring stable clock sources
• Microcontroller system clock generation
• Communication interface synchronization modules

Crystals Procurement Notes

Verify the specific suffix DD074 against official Suntsu documentation to confirm exact tolerance and packaging specifications. Ensure compatibility with HC-49/US footprint requirements during procurement planning. Cross-reference the 24.000 MHz frequency requirement with system design constraints before finalizing orders.

Crystals Selection Notes

Select this component when a 24 MHz reference signal with ±20 ppm accuracy is required. The 12 pF load capacitance must match the oscillator circuit design. Consider the 30 Ohm ESR for drive level limitations. Verify that the HC-49/US package fits the available board space and assembly capabilities.

Crystals Part Context

This part belongs to the Suntsu Electronics crystal oscillator family designed for general-purpose timing applications. Similar models in the series may offer different frequencies or tolerances. The SXTHM212DD074-24.000M specifically targets applications needing reliable 24 MHz performance in a compact surface-mount form factor.

Crystals Replacement Considerations

Direct substitutes include other 24 MHz crystals with matching 12 pF load capacitance and HC-49/US packages. Verify electrical parameters such as ESR and stability before substitution. Ensure pin compatibility and thermal characteristics align with the original design requirements.
