SZK-C-0W07-100-01

$3.29

Description：RF ANT WIFI 6GHZ FLEX ADHES UFL
Series：WOLF
Mfr：Synzen
Package：Tray

SKU:7e9004fa1b4a Category: RF Antennas Brand: Synzen

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SZK-C-0W07-100-01 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Synzen. Its product description is RF ANT WIFI 6GHZ FLEX ADHES UFL. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for SZK-C-0W07-100-01

Description：RF ANT WIFI 6GHZ FLEX ADHES UFL
Series：WOLF
Mfr：Synzen
Package：Tray
RF Family/Standard：Bluetooth, WiFi
Frequency Group：UHF (2GHz ~ 3GHz), SHF (f > 4GHz)
Frequency (Center/Band)：2.45GHz, 5.375GHz, 6.525GHz
Frequency Range：2.4GHz ~ 2.5GHz, 4.9GHz ~ 5.85GHz, 5.925GHz ~ 7.125GHz
Antenna Type：PCB Trace
Number of Bands：3
VSWR：1.84, 2.2, 2.6
Return Loss：-7dB, -8.5dB, -10.1dB
Gain：1.85dBi, 5.5dBi, 3.4dBi
Features：Cable - 100mm
Termination：IPEX MHF1, U.FL (UMCC)
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Adhesive
Height (Max)：0.008" (0.20mm)
Applications：802.11ax, 802.15.4, Bluetooth, Wi-Fi, Wi-Fi 4, Wi-Fi 5, Wi-Fi 6, Wi-Fi 6E
Power - Max：3 W

Antennas RF datasheet and documents for SZK-C-0W07-100-01

SZK-C-0W07-100-01

Antennas RF Overview

The Synzen SZK-C-0W07-100-01 is a flexible adhesive RF antenna designed for wireless communication applications. It supports IEEE 802.11ax, 802.15.4, Bluetooth, Wi-Fi, and Wi-Fi 6 standards operating in the 6 GHz frequency band. The component utilizes an U.FL connector interface and features a flex adhesive form factor for integration.

Antennas RF Feature Summary

Supports multiple wireless protocols including Wi-Fi 6 and Bluetooth
Utilizes a flexible adhesive design for secure mounting
Equipped with an U.FL connector interface

Antennas RF Applications

Wi-Fi 6 module integration
Bluetooth device connectivity
IoT sensor network implementation

Antennas RF Procurement Notes

Verify the specific datasheet to confirm impedance matching and VSWR requirements for your circuit design. Ensure the U.FL connector compatibility aligns with your PCB layout. Confirm that the adhesive backing meets the thermal and mechanical constraints of the intended assembly environment before finalizing procurement.

Antennas RF Selection Notes

Select this model when a low-profile, flexible antenna solution is required for 6 GHz band operations. Consider the adhesive form factor for space-constrained designs where traditional rigid antennas are unsuitable. Verify support for all necessary protocol bands within the target application scope.

Antennas RF Part Context

This part belongs to the Synzen WOLF series of RF antennas. It is engineered for compact wireless devices requiring reliable signal transmission across modern Wi-Fi and Bluetooth standards. The product line focuses on providing versatile connectivity solutions for embedded systems.
