SZK-C-2G19

Antennas RF Overview

The Synzen SZK-C-2G19 is a GNSS flat patch antenna designed for multi-constellation satellite navigation systems. It supports GPS, GLONASS, Galileo, and Beidou frequencies to ensure robust positioning capabilities in diverse environments. The component utilizes an adhesive backing for secure surface mounting on device enclosures or chassis. Signal transmission is facilitated through a U.FL (UMCC) connector, also identified as I-PEX MHF1, allowing direct integration with RF circuits. This configuration provides a compact solution for embedded applications requiring reliable global navigation satellite system reception without the need for external cabling complexity.

Antennas RF Feature Summary

• Supports multiple GNSS constellations including GPS, GLONASS, Galileo, and Beidou
• Features a low-profile flat patch design for discreet integration
• Equipped with adhesive mounting for stable surface attachment
• Utilizes U.FL (UMCC) / I-PEX MHF1 connector interface

Antennas RF Applications

• Global Navigation Satellite System (GNSS) receivers
• Embedded tracking devices
• M2M communication modules
• Industrial automation equipment

Antennas RF Procurement Notes

Verify the specific connector type and frequency band support against your system requirements before ordering. Confirm that the adhesive mounting method aligns with your enclosure material and environmental conditions. Ensure compatibility with the U.FL interface on your PCB or cable assembly. Check RoHS compliance status if required by your manufacturing standards. Request official datasheets from Synzen for precise electrical specifications and mechanical dimensions.

Antennas RF Selection Notes

Choose this antenna when multi-constellation support is critical for location accuracy in challenging signal environments. The flat patch form factor is suitable for space-constrained designs where profile height is limited. The integrated adhesive simplifies assembly processes compared to screw-mounted alternatives. Consider the U.FL connector availability on your target platform to avoid additional adapter components. Evaluate the operating temperature range and environmental sealing needs for your specific application context.

Antennas RF Part Context

This component belongs to Synzen's portfolio of RF antennas, specifically within their GNSS and satellite navigation product lines. Similar models may include variations in connector types, cable lengths, or frequency bands. The SZK-C-2G19 represents a standard flat patch solution for general-purpose navigation applications. Other Synzen products might offer different mounting options or specialized frequency optimizations for distinct regional or technical requirements.

Antennas RF Replacement Considerations

Direct substitutes are not explicitly listed in public documentation. Verify compatibility based on connector type (U.FL/I-PEX MHF1), frequency coverage, and physical dimensions. Alternative antennas must support the same GNSS constellations (GPS, GLONASS, Galileo, Beidou). Ensure any replacement maintains similar gain and radiation pattern characteristics for consistent performance.
