T4F81C2

Field Programmable Gate Array Overview

The T4F81C2 is a Titanium™ field-programmable gate array (FPGA) manufactured by Efinix, Inc. It features 55 general-purpose input/output pins and utilizes a 361-ball FineLine BGA package with dimensions of 13x13 mm. The device operates within a supply voltage range of 0.92V to 0.98V and supports a junction temperature range of 0°C to 85°C. Key internal resources include 7,384 logic elements, 13,110,000 total RAM bits, and integrated DSP capabilities. The component is RoHS3 compliant and classified under ECCN 3A991D.

Field Programmable Gate Array Feature Summary

• Quantum architecture providing reconfigurable logic units for both logic processing and signal routing
• Integrated embedded memory modules and dedicated DSP blocks for high-performance computing
• Supports JTAG programming and configuration via USB interface using FTDI chipsets

Field Programmable Gate Array Applications

• RISC-V processor prototyping and development
• Signal processing applications utilizing embedded DSP resources
• Embedded system control and I/O expansion via PMOD interfaces

Field Programmable Gate Array Procurement Notes

Verify the specific suffix codes against official Efinix documentation to ensure correct package type and temperature rating. Confirm RoHS3 compliance status directly with the manufacturer or authorized distributors prior to ordering. Check for any required software version dependencies when integrating with development kits.

Field Programmable Gate Array Selection Notes

Select this model for designs requiring moderate logic density with significant embedded memory capacity. Ensure the PCB layout accommodates the 361-ball BGA footprint and thermal requirements. Verify that the target application fits within the 55 I/O constraint and that the 0.92V-0.98V core voltage supply is stable.

Field Programmable Gate Array Part Context

This component belongs to the Titanium™ series of FPGAs from Efinix, Inc., which are built on the Quantum™ architecture. The series is designed for applications needing high performance in small form factors, combining programmable logic with embedded memory and DSP blocks.

Field Programmable Gate Array Replacement Considerations

Publicly confirmed substitute part numbers for the T4F81C2 are not available in the provided source data. Consult Efinix technical support for potential cross-references or alternative devices within the Titanium family.
