Product Detailed Parameters
- Description：CMC 2.96MH 12.4A 2LN 2.95KOHM TH
- Series：-
- Mfr：VACUUMSCHMELZE
- Package：Box
- Filter Type：-
- Number of Lines：2
- Current Rating (Max)：12.4A
- DC Resistance (DCR) (Max)：-
- Voltage Rating - DC：-
- Voltage Rating - AC：-
- Operating Temperature：-40°C ~ 130°C
- Ratings：-
- Approval Agency：-
- Features：-
- Mounting Type：Through Hole
- Size / Dimension：1.398" Dia (35.50mm)
- Height (Max)：0.996" (25.30mm)
- Package / Case：Horizontal, 4 PC Pin
- Inductance @ Frequency：2.96 mH @ 100 kHz
- Impedance @ Frequency：2.95 kOhms @ 100 kHz
- Qualification：-
- Grade：-
Download product information
Overview
The VACUUMSCHMELZE T60405R6123X213 is a through-hole common mode choke designed for noise suppression in electronic circuits. It features an inductance of 2.96 mH and an impedance of 2.95 kOhms at 100 kHz. The component supports a maximum DC current of 20 mA and utilizes a two-line configuration. It operates within a temperature range of -40°C to +130°C and complies with RoHS3 standards.
Feature Summary
- Utilizes nanocrystalline material for effective common mode noise attenuation
- Provides high impedance characteristics at 100 kHz for signal integrity
- Designed for vertical PCB mounting via radial leads
Applications
- Power supply input filtering
- Data line noise suppression
- EMI reduction in sensitive electronics
Procurement Notes
Verify the specific suffix X213 against official Vacuumschmelze documentation to confirm pinout and mechanical dimensions. Ensure the 20 mA current rating aligns with circuit requirements. Confirm RoHS3 compliance status directly from the manufacturer's latest datasheet before integration.
Selection Notes
Select this component when low current applications require significant common mode noise rejection. The 2.96 mH inductance offers substantial filtering capability. Verify that the 20 mA DC current limit does not exceed operational peaks. Consider the vertical package profile for board space constraints.
Part Context
This part belongs to the T60405 series of nanocrystalline common mode chokes from Vacuumschmelze. These components are engineered for high-performance EMI suppression in compact form factors. The series is widely used in industrial and consumer electronics where reliable noise filtering is critical.
Replacement Considerations
Cross-reference with T60405R6123X263 for similar specifications but different current ratings. Verify mechanical compatibility and electrical parameters with other T60405 variants before substitution.
