T60405R6128X225

Overview

The T60405R6128X225 is a nanocrystalline common mode choke manufactured by Vacuumschmelze. It features a vertical through-hole mounting style and operates within a temperature range of -40°C to +130°C. The component provides an inductance of 1.01 mH at 100 kHz with a maximum DC current rating of 25A. Its impedance is specified as 970 Ohms at 100 kHz. The device utilizes Vitroperm core material housed in a plastic casing, designed for effective noise suppression in single-phase power lines.

Feature Summary

• Utilizes Vitroperm nanocrystalline core material for high magnetic performance
• Vertical through-hole construction for PCB integration
• Capable of handling high DC currents up to 25A
• Operates reliably across extended industrial temperature ranges

Applications

• Single-phase power line filtering
• Moderate to high-power electronic equipment noise suppression
• Industrial control system EMI mitigation

Procurement Notes

Verify the exact suffix X225 against official Vacuumschmelze documentation to confirm specific electrical tolerances and mechanical dimensions. Ensure compatibility with existing PCB footprints and thermal management requirements before finalizing procurement decisions.

Selection Notes

Select this component when high saturation current and robust common mode rejection are required in vertical mounting configurations. Consider the 25A current rating and nanocrystalline core properties for applications demanding stable performance under heavy load conditions.

Part Context

This part belongs to the T60405 series of common mode chokes from Vacuumschmelze. The series is characterized by the use of Vitroperm nanocrystalline alloys, offering superior low-frequency noise attenuation compared to traditional ferrite cores. These components are engineered for durability in demanding power electronics environments.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided data.
