Product Detailed Parameters
- Description：CMC 16A TH
- Series：-
- Mfr：VACUUMSCHMELZE
- Package：Box
- Filter Type：-
- Number of Lines：-
- Current Rating (Max)：16A
- DC Resistance (DCR) (Max)：-
- Voltage Rating - DC：-
- Voltage Rating - AC：-
- Operating Temperature：-
- Ratings：-
- Approval Agency：-
- Features：-
- Mounting Type：Through Hole
- Size / Dimension：-
- Height (Max)：-
- Package / Case：-
- Inductance @ Frequency：-
- Impedance @ Frequency：-
- Qualification：-
- Grade：-
Download product information
Overview
The T60405-S6123-X216 is a line common mode choke manufactured by Vacuumschmelze. It features a through-hole mounting style with radial termination. The component has an inductance of 800 uH and supports a maximum DC current of 16 A. Its impedance is 1.4 mohms with a tolerance of 3%. The self-resolving frequency is 4.9 MHz. Operating temperature ranges from -40 C to +125 C. It is RoHS compliant and lead-free.
Feature Summary
- Utilizes nanocrystalline Vitroperm core material for high magnetic performance.
- Designed for horizontal PCB mounting via radial leads.
- Provides effective common mode noise suppression in power lines.
Applications
- Power supply input filtering
- Motor drive circuits
- Industrial control systems
Procurement Notes
Verify the exact suffix X216 against official Vacuumschmelze documentation to confirm specifications. Check for end-of-life status or obsolescence notices before procurement. Ensure compatibility with existing PCB footprint and thermal management requirements. Confirm RoHS compliance status if required by specific regulatory standards.
Selection Notes
Select this component when a 16 A current rating and 800 uH inductance are required for common mode noise reduction. Consider the horizontal mounting profile and radial lead configuration for board layout constraints. Evaluate the operating temperature range suitability for the intended environment.
Part Context
This part belongs to the T60405 series of common mode chokes from Vacuumschmelze. The series utilizes nanocrystalline materials known for high saturation flux density. These components are designed for robust industrial applications requiring reliable electromagnetic interference suppression.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided source data. Consult Vacuumschmelze technical support for direct equivalents or cross-reference options based on specific electrical and mechanical requirements.
