T60405S6123X306

Overview

The Vacuumschmelze T60405S6123X306 is a two-line common mode choke utilizing Vitroperm nanocrystalline core technology. It features a horizontal PCB mount configuration with radial termination. Key electrical parameters include an inductance of 7.36 mH and an impedance of 8.65 kOhms at 100 kHz. The component supports a maximum DC current of 7 A and has a tolerance of 5%.

Feature Summary

• Utilizes Vitroperm nanocrystalline material for high magnetic performance
• Designed for horizontal surface mounting on printed circuit boards
• Provides effective common mode noise suppression in two-line configurations

Applications

• Power supply input filtering
• Industrial control systems
• Telecommunications equipment

Procurement Notes

Verify the specific suffix X306 against official Vacuumschmelze documentation to confirm exact electrical characteristics and mechanical dimensions. Ensure compatibility with existing PCB footprints and thermal management requirements before finalizing procurement decisions.

Selection Notes

Select this component when high inductance and impedance are required for common mode noise reduction in compact horizontal layouts. Consider the 7 A current rating and nanocrystalline core properties for applications demanding stable performance under varying load conditions.

Part Context

This part belongs to the T60405 series of common mode chokes from Vacuumschmelze. The series utilizes Vitroperm alloy cores, offering superior magnetic properties compared to traditional ferrites. These components are designed for robust electromagnetic interference suppression in various electronic systems.

Replacement Considerations

Consult official Vacuumschmelze substitution guides for verified alternatives. Generic cross-references may not match the specific nanocrystalline core characteristics or dimensional constraints of the T60405 series.
