T8F49I2X

Field Programmable Gate Array Overview

The Efinix T8F49I2X is a Titanium series Field Programmable Gate Array (FPGA) manufactured by Efinix, Inc. It features 49 general-purpose I/Os and is housed in an 81-ball FineLine BGA package with dimensions of 10x10 mm. The device operates within a supply voltage range of 0.92V to 0.98V and supports a junction temperature range of 0°C to 85°C. Key internal resources include 36 DSP blocks and embedded memory modules designed for signal processing and logic routing applications.

Field Programmable Gate Array Feature Summary

• Integrates Quantum architecture for high-density logic and efficient signal routing within a compact footprint.
• Includes dedicated embedded memory modules and DSP blocks for complex data processing tasks.
• Supports standard configuration methods via SPI NOR flash or JTAG interfaces.

Field Programmable Gate Array Applications

• Industrial automation control systems
• Consumer electronics peripheral interfaces
• Embedded signal processing modules

Field Programmable Gate Array Procurement Notes

Verify the specific suffix 'I2X' against official Efinix documentation to confirm temperature grade and packaging details. Ensure compatibility with the Efinity software environment for design implementation. Confirm RoHS compliance status and moisture sensitivity level requirements prior to integration into manufacturing processes.

Field Programmable Gate Array Selection Notes

Select this component when a low-pin-count FPGA with integrated DSP capabilities is required. Compare resource utilization against the T8F81C2 variant if higher I/O density is needed. Validate that the 81-ball FBGA package fits the target PCB layout constraints and thermal management strategy.

Field Programmable Gate Array Part Context

This part belongs to the Efinix Titanium family, which utilizes the Quantum architecture for scalable logic density. It serves as a cost-effective solution for mid-range programmable logic applications requiring moderate I/O counts and embedded processing resources.

Field Programmable Gate Array Replacement Considerations

Direct substitutes are not publicly confirmed. Evaluate the T8F81C2 for pin-compatible upgrades with increased I/O resources. Verify functional equivalence with other Efinix Trion or Titanium series devices based on specific logic and memory requirements.
