TANGO47/2.5M/SMAM/SMAM/S/S/17

$42.60

Description：4G/LTE MINI WHIP STYLE PANEL MOU
Series：TANGO 47
Mfr：Siretta Ltd
Package：Bulk

SKU:e7788c79a637 Category: RF Antennas Brand: Siretta Ltd

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：4G/LTE MINI WHIP STYLE PANEL MOU
Series：TANGO 47
Mfr：Siretta Ltd
Package：Bulk
RF Family/Standard：Cellular, Navigation
Frequency Group：Wide Band
Frequency (Center/Band)：850MHz, 900MHz, 1.575GHz, 1.8GHz, 1.9GHz, 2.1GHz, 2.7GHz
Frequency Range：-
Antenna Type：Module
Number of Bands：7
VSWR：1.5, 2
Return Loss：-
Gain：2dBi, 3dBi
Features：Cable - 2.5m
Termination：SMA Male (2)
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Panel Mount
Height (Max)：0.630" (16.00mm)
Applications：2G, 3G, 4G, GPS, GSM
Power - Max：-

Download product information

TANGO47/2.5M/SMAM/SMAM/S/S/17

Overview

The Siretta TANGO47/2.5M/SMAM/SMAM/S/S/17 is a combined cellular and GPS antenna designed for panel mounting. It supports 2G, 3G, 4G/LTE, and GPS protocols with a frequency range up to 2.7GHz. The unit features two SMA male connectors and includes a 2.5-meter cable length. Constructed as a weatherproof whip-style antenna with dimensions of 75mm diameter by 16mm height, it provides reliable connectivity for mobile applications.

Feature Summary

Combined support for cellular (2G, 3G, 4G/LTE) and GPS signals
Weatherproof design suitable for outdoor or vehicle environments
Dual SMA male connectors for simultaneous network access

Applications

Mobile vehicle tracking systems
On-the-move communication devices
GPS navigation modules in transit

Procurement Notes

Verify the specific firmware or hardware revision required for your target cellular bands, as regional variations may exist. Confirm that the dual SMA male connector configuration matches your device's input ports. Ensure the 2.5-meter cable length accommodates your installation routing without excessive bending. Check local regulatory compliance requirements for the intended deployment region before finalizing the order.

Selection Notes

Select this model when both cellular data and precise location tracking are required from a single physical unit. The panel mount style is ideal for fixed installations on vehicles or equipment where space is limited. Consider the dual-connector layout if separate antennas would complicate wiring. This solution simplifies integration by combining multiple radio technologies into one compact, weather-resistant package.

Part Context

This component belongs to the Siretta Tango series, which specializes in multi-band antennas for wireless communications. The Tango line typically offers robust solutions for industrial and mobile applications requiring reliable signal reception across various cellular generations and global positioning systems.
